| Compact cabinet |
Yes |
| Weight of the fogging system |
7,5 Kg |
| Overall packaging weight |
8,5 Kg |
| Units on one pallet (100×120 cm) |
42 |
| Dimension of the machine |
L 30,0 x W 13,0 H 39,0 cm |
| Dimension of the packaging |
L 36,0 x W 19,0 x H 45,0 cm |
| Colors |
White - optional black |
| Operating time without mains power |
Over 1 hour |
| Heating time |
Around 2 hours |
| Vertical mounting |
Yes |
| Horizontal mounting |
Yes |
| Usb port for computer monitoring (Windows and Linux) |
Yes |
| Serial interface RS232 |
Yes |
| Lan Connection : Active Cloud |
Optional |
| “Layer” heating system |
Yes |
| Single shot coverage (visibility more than 1,5 m) |
Up to 600 m³ |
| Single shot coverage (visibility less than 1 m) |
Up to 200 m³ |
| Maximum emission time in a single shot |
28 sec |
| Total discharge capability with full bag |
850 m³ |
| Number of bags |
1 |
| Amount of fluid in the bag |
500 ml |
| Shot characteristics |
Programmable in seconds |
| Number of bags included |
1 |
| Two cabled inputs: arming and shooting |
Yes |
| One cabled output: fault (empty bag, low battery/lack of power supply, system failure) |
Yes |
| Top internal riser for optional boards |
Yes |
| Side internal riser for optional boards |
Yes |
| Front panel in plastic material |
Yes |
